Description
Description
The Osburn 3500 Wood Stove with Blower from Osburn
Specifically designed to face the rigors of winter, the Osburn 3500 is an essential for any spacious home, especially in harsh weather conditions. Despite its emissions of 1.6 g/h, this wood stove utilizes user-friendly, non-catalytic technology as well as a significant reduction in fuel consumption. The unit features a firebox that can hold up to 50 lb. of cordwood, as well as a blower, a thermodisc, and an airmate for optimal heat distribution and unparalleled comfort.
A choice of door overlay, a fire screen, and a glass ash lip are available as options.
Osburn 3500 Wood Stove with Blower Performance
| Fuel type | Dry cordwood (16" recommended) | |
| Recommended heating area-ft² | 1,000 - 2,700 | |
| Overall firebox volume-ft³ | 3.5 | |
| EPA loading volume-ft³ | 2.88 | |
| Maximum burn time | 10 h | |
| Maximum heat output-dry cordwood | 110,000 BTU/h (32.2 kW) | |
| Overall heat output rate < | 17,200 BTU/h (5.0 kW) to 57,800 BTU/h (16.9 kW) | |
| Average overall efficiency (dry cordwood) | 71 % (HHV) | 76 % (LHV) |
| Optimum overall efficiency | 77 % | |
| Optimum heat transfer efficiency | 75 % | |
| Average particulate emissions rate | 1.6 g/h | |
| Average CO | 73 g/h | |
Osburn 3500 Wood Stove with Blower Specifications
| Combustion technology | Non-catalytic |
| High-efficiency certified appliance | Yes, EPA 2020 approved |
| Maximum log length | 22" |
| Log positioning | Loading over width and over depth |
| Chimney diameter | 6" |
| Flue outlet diameter | 6" |
| Type of chimney | CAN/ULC S629, UL 103 HT (2100 °F) |
| Minimum chimney height (feet) | 15' |
| Baffle type | C-Cast or equivalent |
| Approved for an alcove installation | Yes |
| Approved for a mobile home installation | Yes, with fresh air intake |
| Shipping Weight | 549 lb (249 kg) |
| Door type | Single, glass with cast iron frame |
| Glass type | Ceramic glass |
| Glass surface – dimensions (Width X Height) | 18 7/8" x 11 3/4" |
| Glass air-wash system | Yes |
| Premium quality blower included (CFM) | 130 |
| Overall dimension (Height) | 34 3/4" |
| Overall dimension (Width) | 28 7/8" |
| Overall dimension (Depth) | 33 1/2" |
| Door opening – dimension (Height) | 9 7/8" |
| Door opening - dimension (Width) | 19" |
| Firebox – dimension (Height) | 12 7/8" |
| Firebox – dimension (Width) | 22 7/8" |
| Firebox – dimension (Depth) | 20 1/8" |
| Firebox lined with refractory bricks for better heat distribution | Yes |
| Stainless-steel secondary-air system improving gas combustion | Yes |
| Model | Pedestal |
| Steel thickness – body | 3/16" |
| Steel thickness – top | 5/16" |
| USA standard (emissions) | EPA |
| Canadian Standard (emissions) | CSA B415.1-10 |
| USA standard (safety) | UL 1482, UL 737 |
| Canadian standard (safety) | ULC S627 |
| Tested and listed as per applicable standards | By an accredited laboratory (CAN/USA) |
| Warranty | Limited lifetime |
Resouces
INSTALLATION MANUAL: Osburn 3500 Wood Stove with Blower
DIMENSIONS: Osburn 3500 Wood Stove with Blower
