NetZero  |  SKU: AA-11-05551

NetZero Fire E-One 160 Bay 3D Electric Fireplace – Ultra-Realistic Fire - 160B

$11,490.00

Images & size shown are for reference only: colors may vary by screen, lighting, & natural material variation. See description for dimensions & finish options or call us to request a sample if an exact match is needed.

This item is available for pick-up or local delivery only (NYC Tri-State NJ CT & Long Island). Call us before ordering if needed immediately. 718-326-4328
400+ five-star Google reviews
  • Local delivery or pick-up across NYC, Long Island, NJ and CT. Delivery is free on this item.
  • Factory-authorized NetZero dealer. You keep the full manufacturer warranty.
  • 30-day returns, no restocking fee.
  • Professional installation available across NYC, Long Island, Westchester, northern NJ and Greenwich/Stamford, CT.
Questions about fit, venting or power? Talk to the team that installs it. Mon to Fri 9 to 5, Sat 10 to 3.
Call 718-326-4328 Free Consultation

Free & Flat Rate Local Delivery
  • Our team & trucks deliver locally within 60 miles of our showroom. (NYC Tri-State including all of Suffolk County)
  • Orders Over $999 Ship Out Fast & Free
  • Delivery typically takes 5 -7 days
  • $49.95 Flat-Rate Local Shipping on orders under $999
  • Setup & Assembly available for most items at checkout

Assembly & Installation

Our company installs in the following areas: Manhattan, Queens, Brooklyn, Nassau, Suffolk, Staten Island, Bronx, & Westchester NY. Hudson, Union, Essex, & Bergen NJ. Greenwich & Stamford, CT. Check out our portfolio of projects we built!
Call for a free quote 877-692-3765

Visit our sister site to learn more about our showroom products like Direct Vent Gas Fireplaces, www.NYCFireplaces.com

Warranty

Manufacturer's warranty their products only if they are purchased from an authorized retailer like us. If an issue occurs and the item was purchased from a 3rd party website i.e. Amazon, your claim may be denied. What this means for you as a customer? As a factory authorized & trained dealer for every brand on our website, you will maintain full manufacturer's warranty. Please click on the manufacturer's manual in the description for full warranty coverage information.

Returns
  • No-Restock Fees
  • 30-Day Return Policy
  • The NYC Fireplaces Team wants you to love what it is that you've ordered! If for some reason you have an issue with your product, we offer a '30-Day Return Policy'.
  • We allow returns on all new, unused, unassembled, and "resalable" items in their original packaging within 30 days of the delivery date for a refund (minus the original shipping costs, and the shipping costs you incur shipping the product back). Naturally, if your return is because of our error, you are not responsible for any shipping costs.

Description

The NetZero E-one 160B (AA-11-05551) is a three-sided bay electric fireplace made in the USA: holographic flames play over sculpted logs behind a front window, with mirrored bay side glass for a view from three directions, and Atmos Heating adds about 5,220 BTU of warmth on a standard 120V circuit.

Nothing to vent and no gas line: it hardwires to a dedicated 15 A circuit, recesses into a framed wall, and can sit below a TV following NetZero's height rules.

Features

  • Holographic flame projection over a sculpted log set, made in the USA
  • Three-sided bay format with mirrored left and right bay glass and bay side panels
  • Atmos Heating: warm air at a 45 degree angle, about 5,220 BTU/hr
  • Flame height 1 to 5 plus shuffle mode; adjustable flame brightness
  • Hybrid LED E ember glow and Atmos Lighting shadow effects, each 1 to 5 plus shuffle
  • Three flame colors and crackling pine or beech wood sound, volume 1 to 5
  • Anti-reflect mode lights the logs with the fire off; remote and Bluetooth app control

Key Specifications

Model NetZero E-one 160B bay (AA-11-05551)
Type Recessed three-sided (bay) electric fireplace
Electrical 120 VAC, 60 Hz, 13.5 A; hardwired to a dedicated 15 A (or higher) circuit
Power 2,100 W
Heat output 5,220 BTU/hr (Atmos Heating)
Standby 11 W
Controls E-one remote and Bluetooth app
Venting None, no gas line or chimney
Origin Made in the USA
Warranty 2 years (NetZero Fire)

Dimensions and Cutout

Recommended framing (W x H x D) 64 x 23 x 19 in.
Finished wall Top guide extends 3/4 in. and bottom/side guides 2-1/4 in. from the face; 5/8 in. wall material recommended
Viewing height Install no higher than 34 in. to the bottom guide
Heat outlet Surfaces above can reach 150 degrees F; use materials rated for it
Mantel Combustible mantel at 1:1, depth to height above the top guide; non-combustible at any height
TV At least 12 in. above the top guide, or lower above a mantel or in a recess
Source NetZero E-one 130B-190B installation manual 85-03-01328

What Is Included and What You Will Need

  • Included: E-one 160B fireplace with front window, log set, bay left and right mirrored glass mounts, bay side panels, E-one remote, adjustable legs, screws, magnets, glass holders, gloves and manual
  • Required: a dedicated 120V 15 A hardwired circuit installed by a licensed electrician, and wall framing to the manual

Installation Notes

Frame to the recommended opening, level the unit on its adjustable legs, fasten the nailing flanges, hardwire the junction box and finish the wall to the guides, following the NetZero manual.

In New York City the hardwired circuit should be run by a licensed electrician. Book a fireplace design consultation to plan the bay wall and TV height.

Documentation

Frequently Asked Questions

Does it need venting or gas?

No. It is electric only and needs a dedicated 120V 15 A circuit.

Can I put a TV above it?

Yes. NetZero recommends at least 12 in. above the top guide, or lower above a mantel or in a recess.

Is it single-sided?

No. This is the bay (three-sided) version with mirrored side glass; single-sided E-one models are listed separately.

Related reading: Electric fireplace buying guide, Best fireplace under a TV.

Warranty

NetZero Fire extends a 2-year warranty to the original purchaser while the fireplace remains at its original place of installation, covering defects in manufacture of factory-assembled components (installation and operation manual). Defective parts are repaired or replaced at NetZero's option through an authorized dealer; installation must follow the manual.
