How to Plan an Outdoor Kitchen: Layout, Appliances, Utilities and Mistakes to Avoid

Most outdoor kitchen problems are decided on paper, months before the first stone is set. The grill ends up at the end of a counter with nowhere to put a platter. The fridge is on a cord run through a window. The propane tank lives in a sealed box with no vents. We have designed and installed outdoor kitchens across Queens, Brooklyn, Long Island, Westchester, New Jersey and South Florida for over 30 years, and this is the planning conversation we have with every client before anyone picks a grill.

Which layout fits your yard: straight run, L, U or island?

Start with the shape, because the shape decides what fits. Four layouts cover almost every yard we work in.

The straight run is the workhorse. It is what most prefab outdoor kitchen islands are, and it is what most Queens and Brooklyn yards have room for. The L is our most common custom build on Long Island: grill on the short leg, out of the traffic, sink and fridge and seating on the long leg. A U is a commitment for when the kitchen is the destination. Whatever the shape, set the grill perpendicular to the dining area so the cook can turn and talk.

How much landing space does a grill need?

Indoors, designers talk about the triangle between sink, stove and fridge. Outside, think in four zones: hot (grill, burners, pizza oven), cold (fridge, ice), wet (sink) and dry (prep and storage). The cold zone should sit next to the wet zone. The hot zone should have open counter on both sides of it.

The landing space numbers matter more than any appliance spec:

• At least 24 inches of open counter on one side of the grill and 12 inches on the other.
• Never put the grill or the sink at the very end of a counter run.
• If a sink sits next to the grill, leave 36 inches of counter between them.
• Where an aisle separates two work zones, keep it 48 inches wide for one cook and 54 inches for two.
• Seating heights: 36 inches for counter stools, 42 inches for bar height, 30 inches for a lowered table section.

A 32 inch grill with the 24 and 12 inch landings is already a 68 inch hot zone. Add a fridge under one landing and you have a 7 foot straight run before you have talked about a sink. That is why 7 and 8 foot islands are the sweet spot.

Which appliances do you actually need?

You do not need all of this. You do need to decide now, because every gas appliance adds load to the line and every electric one needs a circuit.

Grill. The anchor. Most of our clients land on a 32 to 42 inch built-in grill. The Blaze Premium LTE+ 32 is the one we install most because it fits the standard island cutout and the value is hard to argue with. Step up to a Lynx L42TR, a Hestan 42 or a Fire Magic Echelon E790i for heavier steel and burners built to be rebuilt. Order it for natural gas if you have natural gas.

Side burner or power burner. Owner surveys put side burners near the top of the regret list for people who skipped them. A double side burner like the XO 13 inch double burner handles sauces and corn. A power burner such as the Blaze Professional LUX power burner boils a lobster pot and seasons a wok. Pick one based on how you cook.

Refrigeration. Buy outdoor rated. Indoor compact fridges are not built for 95 degree patio air or rain. The outdoor refrigerators we trust include the Blaze 24 inch 5.5 cu. ft. for value and the Dometic E-Series refrigerator drawers when you want drawers instead of a door.

Sink. The most skipped item and the most missed. A drop-in or undermount sink like the Summerset 19 inch undermount needs supply and a drain, so decide before the slab is poured. Without a drain, a Blaze 30 inch beverage center with sink and ice bin running to a dry well still gives you a wash station.

Storage doors and drawers. Every island needs access doors and drawers: a door under the grill to reach the gas valve, drawers for tools. The Blaze 32 inch door and double drawer combo is the standard pairing with a 32 inch grill. Add a sealed dry storage pantry if you want to leave paper goods outside.

Trash. A roll-out trash drawer such as the Summerset 20 inch double trash and recycling bin keeps the bin off the counter and the raccoons out of it. Cheap, and always on the regret list when skipped.

Ice maker. Needs water, a drain and power. The Blaze 50 lb outdoor ice maker uses a gravity drain, so the line has to run downhill. Browse ice makers only if you have all three utilities at that spot.

Pizza oven. Built-in gas ovens like the Lynx Napoli 30 and the Blaze 26 inch built-in oven drop into the counter and share the gas line. See all built-in pizza ovens.

Warming drawer and kegerator. A 120V warming drawer like the Twin Eagles 30 inch holds the first batch while the second cooks. Outdoor rated kegerators need power and shade; Mont Alpi's triple tap kegerator module bolts onto their islands.

What utilities need to be run first? Gas, electric, water and winter

Utilities cost the most to change later, so they get settled before anything is ordered.

Gas

Add up the BTUs. A 32 inch four-burner grill with a rear burner is around 66,000 BTU on its own; a power burner and a pizza oven each add their own load. The total, the pipe length from the meter and the pressure available decide the pipe size. That is the licensed plumber's calculation, which is why we want the appliance list locked before the trench is dug. Two numbers from the Blaze manual worth knowing: natural gas appliances expect about 4 inches of water column at the regulator, propane 11 inches, and the regulator that ships with the grill handles only about half a PSI coming in. Higher pressure needs a second-stage regulator upstream. Put a shutoff inside the island behind an access door. In New York City the whole gas job is licensed master plumber work; more below.

Electric

Fridge, ice maker, lights, rotisserie motor, warming drawer, hood blower. Under the National Electrical Code (210.8), outdoor receptacles at a dwelling must be GFCI protected, so plan on GFCI protection and weatherproof in-use covers. Our electricians run a dedicated 20 amp circuit for refrigeration so a tripped GFCI from a wet rotisserie plug does not thaw your freezer. Low-voltage landscape lighting can share a transformer. Put receptacles inside the island cavity, not just on the face.

Water and drainage

A sink needs cold supply at minimum and a drain. The drain is the hard part: tying into the house sanitary line is the right answer and needs a plumber and a permit; a dry well is the common compromise for a hand-wash sink. Ice makers with gravity drains need continuous fall; a drain pump is the fallback.

Winterizing in the Northeast

Every outdoor water line in New York freezes. Put a shutoff and drain valve inside the house and blow the line out each fall. Kalamazoo's winterization guidance is a good benchmark: blow out ice makers before overnight lows reach 45 degrees, unplug and empty refrigerators once lows hit 38, beverage centers at 42, wine units at 45. Gas appliances need only a cover and a closed valve. Outdoor refrigerators left running through a Queens winter are the most common service call we see.

How does the island get built?

Three paths. We install all three, and we steer people between them based on budget, timeline and whether the yard can take a crane.

The framed masonry island is the classic Long Island build: frame, cement board, veneer, granite. Into it go the grill and the storage components. The appliances are the same across all three paths; what changes is the box.

Prefab islands from Mont Alpi are 304 stainless with a granite top and ship nearly assembled. The Mont Alpi 805 Deluxe 90 degree island with fridge cabinet is an L with a six-burner grill, side burner and refrigeration in one order. They are built for propane; the natural gas conversion kit is a separate part, and in NYC the conversion and hookup is plumber work.

Modular cabinetry is where most of our recent installs have gone. A Challenger Coastal 7 foot island with a Blaze 32 arrives pre-assembled in powder-coated aluminum, and a crew can set it, connect it and be gone in an afternoon. Aluminum versus stainless gets its own guide.

Do you need an insulated jacket and vent panels?

Two parts nobody budgets for, and neither is optional.

An insulated jacket is a double-wall stainless sleeve the grill drops into. Blaze's manual is blunt: islands must be non-combustible, and if the island is combustible the jacket is required. Hestan adds the detail people miss: a wood-framed island with a stucco or tile skin still counts as combustible. Blaze asks for 14 inches of side clearance and 16 inches of rear clearance to combustibles, and 6 feet from countertop to any overhead construction. Steel stud and cement board islands can usually skip the jacket. A wood deck box or pressure-treated frame means the Blaze 32 inch insulated jacket goes on the order.

Vent panels handle gas pooling inside a closed island. Propane is heavier than air and settles low, so LP islands get cross ventilation low. Natural gas rises, so NG islands vent high. Hestan calls for at least three 10 square inch openings on each side of the enclosure. A pair of Blaze 6 by 14 inch vent panels on opposing faces is the usual solution. If a propane cylinder lives inside the island, Blaze also wants a plenum wall separating the tank from the rest of the cavity, or a dedicated tank drawer.

Which countertop, and do you need a vent hood under a roof?

Granite is still the default outdoors in New York: it handles freeze and thaw, shrugs off a hot pan, and darker, denser slabs hide grease. Seal it once or twice a year. Lighter granites with resin fill can yellow in sun.

Porcelain and sintered slabs (Dekton, Neolith and similar) are near zero porosity, UV stable, thin and light. They are brittle at the edges and unforgiving of a bad template, so use a fabricator who has done them outdoors.

Concrete gives you any shape and an integrated sink, but it needs sealing and it will hairline crack. Avoid soft, porous stone: Kalamazoo's countertop guidance names bluestone and some marbles as prone to chipping when water gets into fissures and freezes, which describes a Long Island February exactly.

Covered structures. A pergola or roof changes two things. Blaze's 6 foot clearance from counter to overhead construction applies, and once there is a ceiling you need a vent hood larger than the cooking surface moving at least 1,200 CFM, per the Blaze manual. The Blaze 36 inch 1,000 CFM hood suits a 32 inch grill in open air; under a roof we move to the XO 36 inch 1,200 CFM hood or the Hestan 48 inch 1,200 CFM hood. Hoods need a 120V circuit and a duct path out.

What do NYC and Long Island codes require?

These are the rules we work under. Verify your own situation with your building department and, in a co-op or condo, your board.

• Natural gas grills in NYC must be installed by a New York City licensed master plumber under the NYC Fuel Gas Code, and the piping must be inspected and tested. The Department of Buildings is explicit that no gas work can be performed without an approved LAA filing and a DOB work permit; the plumber files it. Budget time for the inspection and the utility turn-on.
• Commercial grills are not allowed in residences under Fuel Gas Code section 623.2. Buy a residential-listed appliance.
• Propane in multiple dwellings (three or more units) is where NYC is strict: standard 20 pound cylinders cannot be used or stored on a balcony, roof deck, roof, rear yard or courtyard. One- and two-family homes may use a propane grill with no more than two 20 pound tanks on site (Fire Code 307.5.3). This is why most NYC outdoor kitchens are natural gas.
• Charcoal is allowed on a terrace or in a backyard with 10 feet of clearance from the building, and not on a balcony or roof (Fire Code 307.5.1).
• Electric grills are permitted on balconies, terraces, roofs and yards. See the rooftop section.
• Keep every grill 10 feet from anything that can burn, and never on a fire escape.
• Co-op and condo boards can and do set stricter rules than the city. Get written approval before you order.
• Outside the five boroughs, each town on Long Island, in Westchester and in New Jersey runs its own building department. Expect a permit for new gas piping and electrical work, and have the plumber and electrician pull them. Call 811 before anyone digs a trench.

What changes on a rooftop, terrace or small yard?

A lot of our NYC work is a 6 foot run on a Brooklyn roof deck or a Manhattan terrace. Same planning, three twists.

Weight. Roof decks are rated by a structural engineer, not by the contractor's confidence. Powder-coated aluminum cabinetry like Challenger's 5 foot Coastal island with a Blaze 32 weighs a fraction of masonry and can be carried up a stair.

Fuel. In a multiple dwelling, propane is off the table on the roof. That leaves natural gas run by a licensed master plumber, which some buildings will not allow, or electric. The Kenyon Frontier 21 inch built-in electric grill runs on 120V and is legal where gas is not. See our electric grills.

Footprint. In a small yard, a 6 to 8 foot straight run with a 32 inch grill, a door and drawer combo and a Blaze 15 inch outdoor fridge does everything a bigger kitchen does. Skip the sink before you skip the landing space.

What mistakes do we see most?

1. Grill at the end of the run. No landing space on one side, and the lid opens into a wall.
2. Indoor appliances outdoors. An indoor mini fridge lasts one season. Buy outdoor rated.
3. Running the gas after the island is built. Now the plumber is drilling through finished stone.
4. No vent panels. A sealed propane island is a gas trap.
5. Wood framing with no insulated jacket. The stucco skin does not make it non-combustible.
6. Forgetting the trash. Cheapest fix on the list and the most common regret.
7. Cutting the counter to save money. Prep space is the thing you run out of at every party.
8. One GFCI circuit for everything. The rotisserie trips it in the rain, the fridge thaws overnight.
9. Ignoring the board. Co-op approval first, grill second.
10. Leaving the fridge plugged in all winter. Unplug it, empty it, crack the door.

Our recommended models

These are the pieces we spec most often once the layout and utilities are settled. Every one is stocked in the store and each label is used once.

Appliances and components

Best OverallBlazePremium LTE+ 32 Inch Built-In GrillIt fits the standard island cutout, carries a lifetime warranty on burners and body, and is the grill we build the most islands around.View details →Best PremiumHestan42 Inch Built-In Grill with Sear BurnerHeavier steel, a sear burner and a rotisserie make it the anchor for a U or large L where the kitchen is the destination.View details →Best for Big PotsBlazeProfessional LUX Power BurnerA lobster pot, a crawfish boil or a wok needs more heat than a side burner gives, and this is the burner that delivers it.View details →Best Pizza OvenLynxNapoli 30 Inch Built-In Pizza OvenIt drops into the counter beside the grill, shares the natural gas line and doubles as a 700°F roasting oven.View details →Best Value FridgeBlaze24 Inch Outdoor Rated RefrigeratorIt fits the standard 24 inch opening, is rated for patio heat and rain, and costs far less than it would to replace an indoor fridge every season.View details →Best Storage ComboBlaze32 Inch Door and Double Drawer ComboOne cutout under the grill gives you the gas valve access door and two tool drawers, which is why it is the standard pairing with a 32 inch grill.View details →

Prefab and modular islands

Best for Fast InstallsChallengerCoastal 7 Foot Island with Blaze 32A pre-assembled powder-coated aluminum straight run that a crew can set, connect and leave in an afternoon, light enough for a roof deck.View details →Best for L LayoutsMont Alpi805 Deluxe 90 Degree Island with FridgeA six-burner grill, side burner, fridge cabinet and granite top arrive as one L-shaped order in 304 stainless, with no framing trade.View details →

Which should you choose?

The appliances are the same on every path. The decision is how the box gets built.

For a Long Island or Westchester backyard with a slab and a budget for stone, framed masonry with a Blaze LTE+ 32, a door and drawer combo and a 24 inch fridge is the kitchen we build most and the one that holds up. For a Queens or Brooklyn yard or any roof deck, a pre-assembled Challenger Coastal island gets you the same appliances in a day and can be carried up a stair. Pick Mont Alpi when you want an L in one order and are set up for propane. Whichever box you choose, run the gas, water and electric first.

Outdoor KitchensIslandsBuilt-In GrillsDoors & DrawersOutdoor RefrigerationAccessories

Frequently asked questions

How much counter space do I need around a grill?

Plan on at least 24 inches of open counter on one side of the grill and 12 inches on the other, and 36 inches between a grill and a sink. Never put the grill at the end of the run.

Do I need a permit for an outdoor kitchen in NYC?

For the gas, yes. Natural gas piping in New York City must be installed by a licensed master plumber under the NYC Fuel Gas Code with an approved LAA filing and a DOB work permit, then inspected. Electrical work also requires a licensed electrician and permit. The masonry island itself is usually treated like other patio construction; check with your building department and your co-op or condo board.

Can I use a propane grill in my NYC apartment building?

In a multiple dwelling (three or more units) you cannot use or store a standard 20 pound propane cylinder on a balcony, roof, roof deck, rear yard or courtyard. One- and two-family homes may keep up to two 20 pound tanks. Electric grills are allowed on balconies, terraces and roofs, and natural gas grills are allowed when installed by a licensed master plumber.

Do I need an insulated jacket for my built-in grill?

If any part of the island structure is combustible, including wood framing behind stucco, tile or stone, the grill manufacturer requires an insulated jacket. Steel stud and cement board islands, prefab stainless islands and aluminum cabinetry generally do not need one. Check the manual for your specific grill.

Where do the vent panels go on an outdoor kitchen island?

Propane is heavier than air, so an LP island gets cross ventilation low on two opposing faces. Natural gas rises, so an NG island vents high. Most manufacturers want multiple openings per side; Hestan specifies at least three 10 square inch openings on each side.

What is the best countertop for an outdoor kitchen in the Northeast?

Dense granite is the proven choice for freeze and thaw. Porcelain and sintered slabs such as Dekton are excellent and lighter but need an experienced fabricator. Avoid bluestone and marble as a work surface. Seal natural stone once or twice a year.

How do I winterize an outdoor kitchen?

Shut off and blow out the water supply to sinks and ice makers before lows reach 45 degrees. Empty and unplug outdoor refrigerators once lows approach 38 degrees and leave the door cracked. Close the gas valve, clean the grill, and cover everything. Gas grills and pizza ovens need nothing more.

Does an outdoor kitchen under a roof need a vent hood?

Yes. Blaze requires 6 feet from the countertop to any overhead construction and, when a hood is used, a hood larger than the cooking surface moving at least 1,200 CFM. Most of our covered installs use a 36 to 48 inch wall-mount outdoor hood ducted outside.
