Osburn 2000 Wood Insert | OB02016
Osburn 2000 Wood Insert | OB02016 - Black / Regular Faceplate w/Black Trim (29" h x 44" w) / No Thanks is backordered and will ship as soon as it is back in stock.
Description
Description
Available Sizes: Osburn Wood Fireplace Inserts
Osburn 1700 | Osburn 2000 (Current Size) | Osburn 3500
Osburn 1700, 2000 and 3500 wood inserts. Firebox size, heating capacity and required fireplace opening differ by model; confirm your fireplace dimensions before ordering.
Overall Dimensions: 28-3/8" W x 26-3/8" D x 23-1/8" H
The Osburn 2000 is a large-capacity EPA certified wood insert for homeowners who want serious heat from an existing masonry fireplace. It has a 2.4 cubic foot firebox, accepts logs up to 20 inches, and is rated for roughly 500 to 2,100 square feet. An optional faceplate can cover a masonry opening up to 32 inches high and 50 inches wide, in black or brushed nickel.
Key Specifications
| Model | Osburn 2000-I (OB02016) |
|---|---|
| Fuel | Dry cordwood, 16" recommended, 20" maximum log length |
| Combustion | Non-catalytic, EPA certified |
| Maximum Heat Output | 75,000 BTU/h (22 kW) |
| Heat Output Range | 14,200 to 44,500 BTU/h |
| Recommended Heating Area | 500 to 2,100 sq ft |
| Firebox Volume | 2.4 cu ft (EPA loading volume 1.95 cu ft) |
| Maximum Burn Time | 8 hours |
| Efficiency | 72% HHV / 77% LHV average, 79% optimum overall |
| Emissions | 2.3 g/h particulate, EPA / CSA B415.1-10 |
| Flue Outlet | 6" diameter, liner type ULC S635, CAN/ULC-S640 or UL 1777 |
| Blower | Included, up to 144 CFM |
| Door and Glass | Single door, ceramic glass in a cast iron frame, air-wash system |
| Safety Listing | UL 1482, UL 737, ULC-S628 |
| Shipping Weight | 432 lb (196 kg), per current listing |
Dimensions and Cutout
| Overall width | 28-3/8" |
|---|---|
| Overall depth | 26-3/8" |
| Overall height | 23-1/8" |
| Minimum fireplace opening | 28-7/8" W x 23-3/8" H x 15-3/4" D (per current listing) |
| Firebox | 21" W x 11-7/8" H x 16-3/4" D |
| Door opening | 17-1/2" W x 9" H |
| Glass | 17-1/8" W x 10-1/4" H |
| Faceplate options | Regular 29" H x 44" W or Large 32" H x 50" W |
Features
- Revamped version with a 2.3 g/h particulate emissions rate and 79% optimum efficiency
- 2.4 cubic foot combustion chamber lined with refractory bricks
- Stainless steel secondary air system and C-Cast (or equivalent) baffle
- Ceramic glass door with air wash and cast iron frame
- Included blower, up to 144 CFM, to move heat into the room
- Adjustable threaded legs
- Steel door overlay in black or brushed nickel
- Optional faceplate and trims in black or brushed nickel
What Is Included and What You Will Need
- Included: the Osburn 2000-I insert and blower. The door overlay, faceplate and trim are selected in the options.
- Required: a continuous stainless steel liner to the chimney top, minimum chimney height 12 feet. A 6" liner and venting kit with adapter and termination cap can be selected in the Venting option.
- Required: floor protection and hearth as shown in the owner's manual
- Required: dry, seasoned cordwood
Installation Notes
This insert is for installation in an existing masonry fireplace and must be connected to a full-length liner. It is not approved for alcove or mobile home installation. Clearances to combustibles, floor protection and mantel limits are in the owner's manual and must be followed exactly. Use a qualified, certified installer. Wood burning appliances are restricted in New York City, so review our wood burning legality guide and book a design consultation before you order.
Documentation
- Osburn 2000 Wood Insert Owners Manual (Installation and Operation)
- Osburn 2000 Wood Insert Dimensions
Frequently Asked Questions
How much space will it heat?
Osburn recommends 500 to 2,100 square feet. Actual results depend on your home layout, chimney draft, climate and fuel.
What size fireplace opening do I need?
The listing gives a minimum opening of 28-7/8" wide, 23-3/8" high and 15-3/4" deep. Measure before you order, and choose the faceplate that covers the gap around your opening.
Do I need a liner?
Yes. The manual calls for an approved chimney liner, minimum chimney height 12 feet, with a 6" flue outlet.
How long can the logs be?
Osburn recommends 16 inch logs and lists 20 inches as the maximum, loaded east to west.
Related reading: Wood Burning Fireplaces in NYC and How to Measure a Fireplace Opening.
Warranty
Osburn Limited Lifetime Warranty for the original retail purchaser. The combustion chamber welds and cast iron door frame carry lifetime parts coverage and 5 years of labor. Blower, switches and wiring are covered for 2 years parts and 1 year labor. Coverage varies by component, so read the full terms in the owner's manual.
