Description
Description
Explore other Infratech C-Series 240V single-element heater sizes in Bronze: 33 inch / 1500W | 39 inch / 2000W (current) | 61.25 inch / 3000W | 61.25 inch / 4000W
Overall Dimensions: 39 in long, C-shaped body about 2-1/2 in deep, per Infratech
The Infratech C2024 is a 39 in single element electric infrared heater, 2,000 W on 240 V, in a bronze powder coat over 304 stainless steel finish. It is sized for a café table, a grill station or a small seating group, and medium wave quartz infrared warms people and surfaces directly instead of the air, so a breeze does not carry the heat away. The C-Series uses a C-shaped 304 stainless steel body about 2-1/2 in deep with two inset swivel brackets that give it a floating look on a wall or ceiling.
Features
- 2,000 W single quartz element, 6,824 BTU per Infratech
- Medium wave infrared: a soft glow with no odor, no combustion and no fuel to refill
- Works with an Infratech INF input regulator for variable heat
- Surface mounts to a wall or ceiling on swivel brackets (30 to 60 degrees on a wall, up to 30 degrees on a ceiling)
- Bronze finish; Infratech offers brushed stainless plus eight standard colors and custom colors
- UL listed for indoor and outdoor use; made in the USA by Infratech in Gardena, California
Key Specifications
| Model / SKU | Infratech C-Series C2024, Bronze finish (C2024BR) |
| Elements | Single medium wave quartz, 2,000 W total |
| Voltage / amps | 240 V, 8.3 A |
| Heat output | 6,824 BTU (Infratech CAD drawing) |
| Coverage | 6 x 6 ft average, 4 x 4 ft cold, 8 x 8 ft protected |
| Recommended mounting height | 7 to 8 ft |
| Replacement element | E-2024 (2,000 W, 240 V) |
| Housing | 304 stainless steel, C-shaped body |
| Wiring | Hardwired by a licensed electrician; 1/2 in knock-out |
| Listing | UL listed for indoor and outdoor use |
Dimensions and Cutout
| Length | 39 in (Infratech CAD drawing) |
| Body depth | About 2-1/2 in (Infratech C/W comparison) |
| Clearance to combustibles | 6 in behind, 18 in from the sides and ends, 36 in in front |
| Wall / ceiling mount | 18 in from adjacent walls; 12 in (wall) or 6 in (ceiling) from the ceiling; 6 ft minimum height (8 ft UL/CUL) |
What Is Included and What You Will Need
- Infratech C2024 heater in bronze, with surface mounting brackets
- You will need: a dedicated 240 V circuit and disconnect installed by a licensed electrician with outdoor-rated fittings, and a control rated for the load (sold separately)
Optional Accessories
- Infratech single INF input regulator, flush mount, 240 V (14-4210)
- Infratech single INF input regulator, stainless steel wall plate, 240 V (14-4200)
- Infratech Single On/Off Wall Switches
- Infratech replacement element E2024 (2000 W, 240 V)
Installation Notes
Infratech requires the heater to be permanently installed and hardwired by a licensed electrician to the National Electrical Code and local code. Hold the clearances above, keep cords and drapery at least 3 ft from the front and flammable materials 25 ft away, and mount it level, angled down about 45 degrees for the best spread (30 to 60 degrees on a wall, up to 30 degrees on a ceiling).
At 8.3 A the C2024 is within the 15 A limit of an Infratech INF input regulator, which pulses the element to vary the heat, or it can run on a simple on/off switch. In New York City, a hardwired outdoor heater is electrical work for a licensed electrician, and terrace or rooftop installs in multifamily buildings often need building or board approval.
Planning heat for a covered patio, pergola or terrace? Book a design consultation and we will help size and place the heaters.
Documentation
- Infratech C and CD-Series Installation, Use and Care Manual (2024)
- Infratech C and CD-Series Heater CAD Drawing (current)
- Infratech Limited Warranty (2024)
Frequently Asked Questions
How much area will it heat?
Infratech rates the C2024 for about 6 x 6 ft average, 4 x 4 ft in cold conditions and 8 x 8 ft in a protected space, from a 7 to 8 ft mounting height. Wind and cold reduce coverage; a protected space does better.
Does it plug in?
No. It is hardwired on a 240 V circuit by a licensed electrician.
Can I use it indoors?
Yes. Infratech heaters are UL listed for indoor and outdoor use, with the same clearances.
Can a C-Series heater be flush mounted?
No. The C-Series is Infratech's surface mount body. For a recessed look choose the W-Series with an Infratech flush mount frame.
Related reading: Patio heater buying guide, Best patio heater for a covered patio, Bromic vs Infratech patio heaters.
Warranty
Infratech backs its heaters with a three-year limited warranty when the heater is registered (online at infratech.com/warranty or by returning the registration card within 30 days of purchase). The warranty covers manufacturer replacement parts only; labor to remove, repair or reinstall is excluded, and damage from improper installation, misuse, harsh cleaning chemicals or non-Infratech controls may void coverage. Keep your proof of purchase.
