Marquis Serene 60" Direct Vent Linear Gas Fireplace ZCVRB60

Overall Dimensions: 66-3/16" W x 19-1/4" D x 39-9/16" H

The Marquis Serene 60 (ZCVRB60) is a 60 inch linear direct vent gas fireplace from Marquis by Kingsman, built for living rooms and primary suites where a wide, low ribbon of flame is the focal point. Choose a millivolt or IPI valve system, and dress the burner with rocks, birch and driftwood, decorative stones, cannonballs or ember glass to set the look.

Key Specifications

Dimensions and Cutout

Features

• Millivolt or IPI valve system operates during power failures (per listing)
• Proflame 2 models include a remote for flame, fan, thermostat, smart thermostat (Wi-Fi compatible) and non-dimmable LED lights
• Bronze glass
• Safety screen barrier
• Mobile home, bedroom and bed sitting room approved (per listing)
• Choice of rocks, birch and driftwood, decorative stones, cannonballs or ember glass

What Is Included and What You Will Need

• Per the manual: burner assembly, media tray, safety screen, nailing tabs and stand-offs. Decorative glass embers must be on the burner and media tray before operation. The manual lists log sets, liners, fan kit (Z46FK) and light kit (ULK64) as optional accessories, so confirm what ships with your configuration.
• Required: direct vent pipe, a firestop or attic insulation shield for vertical venting through the enclosure top, a gas line, and a grounded outlet for IPI and Proflame 2 models
• Optional: surround (ZCVRB60S1BL/SS), tile lip kit, remote and IPI controls

Installation Notes

Clearance to combustibles is 36 inches at the front and 0 inches at the back, sides, top and floor. Natural gas supply pressure is 5.5 to 9 in. w.c. and propane is 11 to 12 in. w.c. Do not operate without the decorative glass or with the glass front removed. Gas and venting work must be done by a licensed installer. In New York City, a direct vent gas fireplace must meet the NYC Fuel Gas Code and be permitted. Request a consultation and we will confirm venting and framing before you buy.

Documentation

• Serene 60 Manual
• Serene Brochure
• Wall Temperature Guide
• Proflame II Manual
• Proflame II Remote
• Proflame II WIFI Manual
• Marquis Collection Brochure

Frequently Asked Questions

What is the difference between millivolt, IPI PF1 and IPI PF2?

Millivolt keeps a standing pilot lit and can be upgraded by a dealer for full function remotes. IPI Proflame 1 is the basic intermittent pilot system, and IPI Proflame 2 adds a factory installed full function remote.

Does it need a vent pipe?

Yes. It is a direct vent fireplace that uses 5 inch flex or 8 inch hard pipe through the top vent.

Are the logs included?

The manual treats log sets as optional accessories, while decorative glass embers are required on the burner. Confirm your configuration with us before ordering.

Related reading: Direct Vent Gas Fireplace Buying Guide and Linear vs. Traditional Fireplace.

Warranty

Per the current listing, Marquis provides a 1-year limited warranty on parts and labor, with a lifetime warranty on the heat exchanger, combustion chamber and burner for the original owner. Confirm exact terms in the owner's manual.
