Description
Description
Overall Dimensions: 45-1/2 in. W x 24-3/4 in. H, glass 40 in. x 16-3/4 in., per Superior spec sheet 900994-01
The Superior DRL3545 is a 45 in. linear direct vent gas fireplace from the DRL3500 series, which adds interior lights and a blower to the DRL2000 base model. It has a 40 in. x 16-3/4 in. glass view over platinum glass media, electronic ignition with AA battery backup and a remote control, rated 23,000 BTU/h on natural gas. An optional HeatFlo kit routes heat above the opening so a TV or art can go closer to the fire.
Key Specifications
| Models | DRL3545TEN (natural gas), DRL3545TEP (propane) |
| Input, natural gas | 16,000 to 23,000 BTU/h |
| Input, propane | 17,000 to 21,000 BTU/h |
| Efficiency | AFUE 66.9% NG / 61.9% LP; P4 62.4% NG / 65% LP |
| Glass viewing area | 40 in. W x 16-3/4 in. H |
| Venting | Direct vent, Secure Vent SV4.5 concentric pipe; up to 60 ft vertical, 25 ft horizontal per manual figure |
| Ignition | Electronic intermittent pilot; external power required, 4 AA battery backup (blower excluded) |
| Gas pressure | NG inlet 5 to 10.5 in. w.c.; LP inlet 11 to 13 in. w.c. |
| Certification | ANSI Z21.88 / CSA 2.33 vented gas fireplace heater |
| Shipping weight | 126 lb |
Dimensions and Cutout
| Unit width / height | 45-1/2 in. W x 24-3/4 in. H per spec sheet |
| Framing | Minimum opening width 45-7/8 in. (add 1/8 in. per side recommended); corner framing 70-3/8 in.; see spec sheet table for height and depth |
| Shelf above (top vent, one 90 elbow) | 52 in. with rigid Secure Vent, 54 in. with Secure Flex |
| Venting note | At least 1 ft of vertical rise off the top of the unit is strongly recommended on 45 in. models |
| HeatFlo kit framing | Flush wall or recessed pocket configurations per spec sheet; 81-1/2 in. minimum appliance base to ceiling |
Features
- 45 in. linear clean-face design
- Interior lighting and blower standard on DRL3500 models
- Platinum glass media (5 lb) included
- Electronic ignition with AA battery backup
- Remote control included
- Optional HeatFlo kit for TV and art placement
- Optional reflective black glass or porcelain liners and decorative media
- Mantel clearance chart down to 6 in. depth at reduced heights
What Is Included and What You Will Need
- Included: fireplace, remote control, 5 lb platinum glass media, 4.75 in. non-combustible board with brackets, elbow and header heat shields, wall heat shield, 2 vent restrictors, minimal vent run baffle
- Required: Superior Secure Vent SV4.5 direct vent pipe and termination (sold separately), 120 V power, gas line with shutoff
- Optional: HeatFlo kit, liners, log sets and alternate media, facade
Installation Notes
A qualified gas installer must vent the DRL3545 with Superior Secure Vent components inside the manual limits and connect 120 V power (the AA batteries are only a backup). In New York City, gas work requires a licensed master plumber and permits; direct vent units are a common NYC-compliant choice. Book a free design consultation and we will help you plan the layout, utilities and installation.
Documentation
Frequently Asked Questions
What is the difference between DRL2045 and DRL3545?
The DRL3500 series adds interior lights and a blower; the 45 in. DRL3545 is also rated higher, at 23,000 BTU/h on natural gas.
Does it work in a power outage?
The ignition and burner run on 4 AA backup batteries during an outage; the blower does not.
Can I put a TV above it?
Superior offers the HeatFlo kit to redirect heat above the opening; framing for the kit is in the spec sheet.
What vent pipe does it use?
Superior Secure Vent SV4.5 concentric direct vent pipe.
Related reading: Direct Vent Gas Fireplace Buying Guide and Linear vs Traditional Fireplace.
Warranty
Superior (Innovative Hearth Products) limited 20-year warranty per installation manual 900994-00; component terms are listed in the warranty that ships with the fireplace.
