Description
Description
Overall Dimensions: 40-1/4 in. W, glass 34-1/4 in. x 24-1/2 in. (framing 40-7/8 in. W x 41-1/4 in. H x 18-1/2 in. D), per Superior spec sheet 901276-01
The Superior DRT3540 (DRT3500-E series) is a 40 inch traditional direct vent gas fireplace with a 34-1/4 in. by 24-1/2 in. glass view, an oak log set with glowing and platinum embers, and a remote control in the box. It is rated up to 33,000 BTU/h on natural gas, enough to be a real heat source in a mid-size living room.
Superior requires a firebox liner kit and a facade or barrier, chosen separately, to finish the fireplace before first use, which lets you pick the interior and face to suit the room.
Key Specifications
| Models | DRT3540DEN-E (natural gas), DRT3540DEP-E (propane) |
|---|---|
| Input, natural gas | 23,000 to 33,000 BTU/h |
| Input, propane | 20,000 to 27,000 BTU/h |
| Efficiency (P4) | 62.4% NG / 62.6% LP |
| Glass viewing area | 34-1/4 in. W x 24-1/2 in. H |
| Venting | Direct vent, Secure Vent SV4.5, Secure Flex or Z-Flex (4-1/2 in. inner / 7-1/2 in. outer); 60 ft maximum combined |
| Ignition | Electronic; external power required, AA battery backup |
| Gas pressure | NG inlet 5 to 10.5 in. w.c.; LP inlet 11 to 13 in. w.c. |
| Certification | ANSI Z21.88 / CSA 2.33 and CSA 2.17 vented gas fireplace heater (PFS F13-094); listed for bedrooms and manufactured homes |
| Shipping weight | 150 lb |
Dimensions and Cutout
| Unit width | 40-1/4 in. |
|---|---|
| Framing (W x H x D) | 40-7/8 in. minimum x 41-1/4 in. x 18-1/2 in. (with 1/2 in. drywall) |
| Minimum framing height | 43-3/4 in. top vent; 28-1/4 in. rear vent |
| Shelf above (top vent, one 90 elbow) | 52 in. rigid Secure Vent, 54 in. Secure Flex |
| Mantel and side wall | 3-1/2 in. mantel clearance reference; 6 in. side wall clearance |
Features
- 40 in. traditional firebox with a 34-1/4 x 24-1/2 in. view
- Up to 33,000 BTU/h on natural gas
- Oak log set with glowing and platinum embers
- Remote control and receiver included
- Electronic ignition with AA battery backup
- Top or rear venting
- Choice of firebox liner kit and Vista facade to finish the face
What Is Included and What You Will Need
- Included: fireplace, remote control and receiver, oak log set, glowing and platinum embers, non-combustible board with brackets, header shield, wall heat shield, elbow shields, 2 vent cover plates, 2 vent restrictors
- Required, sold separately: firebox liner kit and a facade or barrier (Superior lists Vista facade F5026 for the 40 in.), both installed before operation
- Required: Secure Vent SV4.5 pipe and termination, external power, gas line with shutoff
Installation Notes
A qualified gas installer must frame, vent and wire the DRT3540 per manual 901276-00 and install the liner kit and facade before first use. Rear vent runs allow up to 8 ft horizontal with one elbow and at least 3 ft of vertical. In New York City, gas work requires a licensed master plumber and permits, and sealed direct vent fireplaces like this one are a common code-compliant choice. Book a free design consultation and we will help you plan the layout, utilities and installation.
Documentation
- Superior DRT3500-E Specification Sheet 901276-01
- Superior DRT3500-E Installation and Operation Manual 901276-00
Frequently Asked Questions
Is a liner included?
No. Superior requires a firebox liner kit and a facade or barrier, sold separately, installed before the fireplace is operated.
How much heat does it make?
23,000 to 33,000 BTU/h on natural gas and 20,000 to 27,000 BTU/h on propane per the Superior manual.
Can it go in a bedroom?
Superior lists the DRT3500-E for bedroom installation; local code still governs.
Does it come with a remote?
Yes, a remote control and receiver are packaged with the fireplace.
Related reading: Direct Vent Gas Fireplace Buying Guide and Gas Fireplace Cost Installed.
Warranty
Superior (Innovative Hearth Products) limited warranty as printed in installation manual 901276-00, with shorter terms for listed components. Ask us for the warranty document that ships with your unit.
