Marquis by Kingsman 3 Piece Reflective Porcelain Panel Liner F451PL

The Marquis by Kingsman F451PL is the porcelain reflective liner (1 back and 2 side panels) for the Kingsman FDV451 Vantage free standing direct vent gas stove. The Vantage manual lists F451PL as one back liner and two side liners, and the Marquis MQFDV453 uses the back-only MQ453PL instead. Black porcelain panels reflect the flame for a deeper, brighter looking fire.

Features

• Porcelain reflective liner, 1 back and 2 side panels
• For the Kingsman FDV451 Vantage free standing direct vent gas stove
• Porcelain enamel panels reflect the flame

Key Specifications

What Is Included and What You Will Need

• Included: F451PL liner (1 back and 2 side panels), per current listing
• Required: Kingsman FDV451 Vantage stove
• Alternatives: F451RLT traditional brick or F451RLH herringbone brick liner

Installation Notes

Per the Vantage manual, ease the back liner past the pilot area (it is held by the angle at the top of the firebox), then fit the side liners. Liners are fragile, so handle them with care. In New York City, gas stoves are installed under the NYC Fuel Gas Code by a licensed master plumber, with DOB filing where required.

Book a design consultation to choose the liner and media together.

Documentation

• Kingsman FDV451 / Marquis MQFDV453 Vantage Stove Installation Manual
• Marquis Vantage Stove Brochure
• Kingsman Product Guide 2020 (accessory charts)

Frequently Asked Questions

Which fireplace does it fit?

The Kingsman FDV451 Vantage stove (FDV451N, NE, NE2, LP, LPE, LPE2). Check the rating plate model number before ordering.

Does it fit the MQFDV453?

The manual lists MQ453PL (back liner only) for the MQFDV453; F451PL is the FDV451 set.

Related reading: Direct vent gas fireplace buying guide, NYC fireplace code guide.

Warranty

Kingsman limited warranty, per the Kingsman and Marquis manuals: in the first year after installation, Kingsman replaces any component part found defective in materials or workmanship, with labor at its rate schedule through an authorized Kingsman dealer (accent light bulbs, gasketing and paint excluded). The lifetime term covers the fireplace heat exchanger, combustion chamber and burner, not accessories, and applies only at the original installation site in the United States or Canada. The manuals note that warping and discoloration of porcelain or painted metal liners is normal and not covered.
