Description
Description
Overall Dimensions: 35-1/2 in. W x 24-3/4 in. H x 17 in. D
The Superior DRL2000 35 in. linear direct vent gas fireplace (DRL2035) is the compact clean-face model of Superior's DRL linear line, with a 30 in. wide view over black glass media. It suits bedrooms, dens and smaller living rooms where you want a modern linear flame on a modest wall.
Superior rates it at 15,000 BTU/h high and 13,000 low on natural gas, with 68.9% AFUE. Electronic ignition with a four AA battery backup keeps it running through a power outage, and it is listed for bedroom installation.
Key Specifications
| Models | DRL2035TEN (natural gas), DRL2035TEP (propane) |
|---|---|
| Type | Linear direct vent gas fireplace, sealed combustion |
| Input, natural gas | 15,000 BTU/h high, 13,000 low |
| Input, propane | 14,000 BTU/h high, 12,000 low |
| Efficiency | 68.9% AFUE NG, 53.7% AFUE LP; P4 63.64% NG, 62.8% LP |
| Ignition | Electronic intermittent pilot with 4 AA battery backup |
| Viewing area | 30 in. W x 16-3/4 in. H |
| Media | Black glass media |
| Venting | 4-1/2 in. / 7-1/2 in. Secure Vent or Secure Flex, top vent |
| Weight | 101 lb shipping |
| Listing | ANSI Z21.88 / CSA 2.33, vented gas fireplace heater; listed for bedrooms |
Dimensions and Cutout
| Width | 35-1/2 in. |
|---|---|
| Height | 24-3/4 in. |
| Depth | 17 in. |
| Framing (standard) | 35-7/8 in. W x 29 in. H x 18 in. D for flush framing; 2 x 4 or larger |
| Vent framing height | 42 in. with a 12 in. section then an elbow; 31-1/2 in. with an elbow directly off the unit |
| Corner framing | 59-1/2 in. wall to wall |
Features
- 30 in. wide linear flame over black glass media
- Clean-face design that finishes flush with the wall
- Electronic ignition with 4 AA battery backup for power outages
- 15,000 BTU/h on natural gas, adjustable to 13,000
- 68.9% AFUE on natural gas
- Optional porcelain liners, glass media colors and driftwood logs
- Listed for bedroom installation
- Superior strongly recommends 1 ft of vertical vent rise directly off the unit
What Is Included and What You Will Need
- Included: fireplace with safety barrier, black glass media, non-combustible board with brackets, 15 ft of two-conductor wire, vent restrictors and minimal vent run baffle, per the DRL manual for DRL2000 models
- Optional: remote control or wall switch, porcelain liner and alternate glass media
- Required: Superior Secure Vent 4-1/2 in. / 7-1/2 in. components such as the SV4.5L6 rigid vent section and, for attic runs, the SV4.5RSA attic insulation shield
- Required: gas line and 120V power
Installation Notes
The DRL2035 frames into a 35-7/8 in. W x 29 in. H opening with 18 in. of depth for flush framing and vents from the top with Superior's 4-1/2 in. / 7-1/2 in. Secure Vent or Secure Flex; Superior strongly recommends at least 1 ft of vertical rise directly off the unit. It needs 120V power, with the AA battery pack keeping the burner running in an outage. Mantel and shelf heights are set out in the manual. Installation must be done by a qualified, licensed installer. In New York City, direct vent gas fireplaces are installed under the NYC Fuel Gas Code by a licensed plumber with DOB filing where required, and the vent termination location usually decides feasibility. Book a free design consultation and we will help you plan the layout, utilities and installation.
Documentation
Frequently Asked Questions
Is this an indoor or outdoor fireplace?
Indoor. The DRL2035 is a sealed direct vent fireplace listed as a vented gas fireplace heater, including for bedrooms.
Will it run during a power outage?
Yes. Four AA batteries back up the electronic ignition and burner.
How much wall space does it need?
Frame 35-7/8 in. wide, 29 in. high and 18 in. deep for a flush install, plus room above for the vent.
What is the difference between the DRL2000 and DRL3500?
The DRL3500 adds lights, a blower, a remote and a higher BTU rating. The DRL2000 is the simpler clean-face model with black glass media.
Related reading: Direct Vent Gas Fireplace Buying Guide and Linear vs. Traditional Fireplace.
Warranty
Superior (Innovative Hearth Products) 20 Year Limited Warranty, per the installation manual: the product body, firebox and barrier are covered for 20 years, and ceramic glass for 20 years against thermal breakage only, with IHP paying its prevailing labor rates on covered repairs for up to five years. The burner, gas components and gaskets are covered for 1 year, logs for 1 year against thermal breakage, optional blowers and remote controls for 1 year, tempered glass for 1 year, and optional glass doors and unlisted parts for 90 days. Vent components, trim and paint are excluded. Coverage is for the original owner only, requires purchase from a listed IHP supplier with proof of purchase, and requires installation and repair by an IHP-approved licensed contractor.
