Description
Description
Available Superior DRT4000 fireplace sizes: 40 inch (this size) | 45 inch
Overall Dimensions: 37-1/8 in. W front, glass 34-1/4 in. x 24-1/2 in. (framing 40-7/8 in. W x 41-1/4 in. H x 23 in. D), per Superior spec sheet 901277-01
The Superior DRT4040 (DRT4000-E series) is a 40 inch traditional direct vent gas fireplace with a deep firebox that needs 23 in. of framing depth, a log set with volcanic stone and glowing embers, and wall switch control. It is rated up to 28,000 BTU/h on natural gas.
It is the value step below the DRT4240, which adds a remote and required liners. Liners are not required on the DRT4040, so it can be finished with the standard firebox.
Key Specifications
| Models | DRT4040TEN-E (natural gas), DRT4040TEP-E (propane) |
|---|---|
| Input, natural gas | 20,000 to 28,000 BTU/h |
| Input, propane | 18,000 to 25,000 BTU/h |
| Efficiency (P4) | 57.1% NG / 58.6% LP |
| Glass viewing area | 34-1/4 in. x 24-1/2 in. |
| Venting | Direct vent, Secure Vent SV4.5; a 40 in. model may connect an elbow directly to the top flue collar |
| Ignition and control | Electronic, wall switch (15 ft wire included); external power required |
| Certification | ANSI Z21.88 / CSA 2.33 and CSA 2.17 vented gas fireplace heater (PFS TECO 16-120) |
| Shipping weight | 210 lb |
Dimensions and Cutout
| Front width | 37-1/8 in. |
|---|---|
| Framing (W x H x D) | 40-7/8 in. minimum x 41-1/4 in. x 23 in. (with 1/2 in. drywall) |
| Minimum height, top vent | 43-3/4 in. |
| Shelf above (top vent) | 52 in. rigid Secure Vent elbow, 54 in. Secure Flex |
| Clearances | Back 1-1/2 in. to wrapper, sides 1/2 in. to wrapper, 0 in. to spacers and standoffs, floor 0 in., 64 in. unit bottom to ceiling, 3 ft front service |
Features
- 40 in. traditional firebox with deep log presentation
- Log set with volcanic stone and glowing embers
- Electronic ignition with wall switch control
- Liners not required on DRT4000-E models
- Top or rear venting with Secure Vent SV4.5
- Optional FBK-250 variable speed blower and lighting
- Optional remote control systems
What Is Included and What You Will Need
- Included: fireplace, log set, volcanic stone, glowing embers, non-combustible board with brackets, 2 elbow heat shields, header heat shield, 2 vent cover plates, 2 vent restrictors, 15 ft two-conductor wire
- Required: Secure Vent SV4.5 pipe and termination, external power, gas line with shutoff
- Optional: Superior FBK-250 variable speed blower (needs its own switched circuit), lighting, remote
Installation Notes
Frame to 40-7/8 in. x 41-1/4 in. x 23 in., vent with Superior Secure Vent and bring external power to the unit per manual 901277-00. If you want the optional blower, run its circuit to a wall switch during rough-in. In New York City, gas work requires a licensed master plumber and permits, and sealed direct vent fireplaces like this one are a common code-compliant choice. Book a free design consultation and we will help you plan the layout, utilities and installation.
Documentation
- Superior DRT4000-E / DRT4200-E Specification Sheet 901277-01
- Superior DRT4000-E / DRT4200-E Installation and Operation Manual 901277-00
Frequently Asked Questions
Does the DRT4040 include a remote?
No. The remote and receiver are packaged only with DRT4200-E models; the DRT4040 uses a wall switch.
How much heat does it make?
20,000 to 28,000 BTU/h on natural gas and 18,000 to 25,000 BTU/h on propane per the Superior manual.
How deep is the framing?
23 in., with a 41-1/4 in. height and a 40-7/8 in. minimum width.
Do I need a liner?
No. Superior requires liners only on DRT4200-E models.
Related reading: Direct Vent Gas Fireplace Buying Guide and Gas Fireplace Cost Installed.
Warranty
Superior (Innovative Hearth Products) limited 20-year warranty per installation manual 901277-00; component terms are listed in the warranty that ships with the fireplace.
