Description
Description
Overall Dimensions: 35-1/2 in. W x 24-3/4 in. H, glass 30 in. x 16-3/4 in., per Superior spec sheet 900994-01
The Superior DRL3535 is the 35 inch model in the DRL3500 linear direct vent series, which adds factory interior lights, a blower and a remote control to the DRL2000 base design. Its 30 in. by 16-3/4 in. glass view over platinum glass media makes it a strong pick for bedrooms, studies and smaller living rooms that still want a modern linear fire.
It is rated up to 18,000 BTU/h on natural gas, with electronic ignition on house power and an AA battery backup.
Key Specifications
| Models | DRL3535TEN (natural gas), DRL3535TEP (propane) |
|---|---|
| Input, natural gas | 12,000 to 18,000 BTU/h |
| Input, propane | 13,000 to 16,000 BTU/h |
| Efficiency | AFUE 69.2% NG / 55.3% LP; P4 65.11% NG / 63.1% LP |
| Glass viewing area | 30 in. W x 16-3/4 in. H |
| Venting | Direct vent, Secure Vent SV4.5 (4-1/2 in. inner pipe); up to 60 ft combined, 25 ft horizontal |
| Ignition | Electronic; external power required, 4 AA battery backup (blower excluded) |
| Gas pressure | NG inlet 5 to 10.5 in. w.c.; LP inlet 11 to 13 in. w.c. |
| Certification | ANSI Z21.88 / CSA 2.33 vented gas fireplace heater (PFS TECO F19-008) |
| Shipping weight | 101 lb |
Dimensions and Cutout
| Unit width x height | 35-1/2 in. x 24-3/4 in. |
|---|---|
| Framing opening width | 35-7/8 in. minimum (about 1/8 in. extra per side recommended) |
| Other framing dimensions | Height, depth and chase dimensions are in the spec sheet framing table |
| Combustible shelf above (top vent, one 90 elbow) | 47 in. with Secure Vent, 49 in. with Secure Flex |
| Vent note | At least 1 ft of vertical rise directly off the unit is strongly recommended |
Features
- 35 in. linear clean-face design
- Interior lights and blower standard on DRL3500 models
- Remote control included
- Platinum glass media included (3.5 lb)
- Electronic ignition with AA battery backup
- Top venting with Superior Secure Vent SV4.5 or Secure Flex
- Optional liners and alternate media
What Is Included and What You Will Need
- Included: fireplace, remote control, 3.5 lb platinum glass media, 4.75 in. non-combustible board with brackets, elbow and header heat shields, wall heat shield, 2 vent restrictors, minimal vent run baffle
- Required: Secure Vent SV4.5 pipe and termination (sold separately), external power, gas line with shutoff
- Optional: liners, alternate media, facade
Installation Notes
A qualified gas installer must frame and vent the DRL3535 with Superior Secure Vent components inside the manual limits and supply external power; the AA batteries are a backup only and do not run the blower. In New York City, gas work requires a licensed master plumber and permits, and sealed direct vent fireplaces like this one are a common code-compliant choice. Book a free design consultation and we will help you plan the layout, utilities and installation.
Documentation
- Superior DRL2000 / DRL3500 Specification Sheet 900994-01
- Superior DRL2000 / DRL3500 Installation and Operation Manual 900994-00
Frequently Asked Questions
What does the DRL3535 add over the DRL2035?
Superior lists the DRL3535 with lights and a blower, plus a remote, and rates it higher at 18,000 BTU/h on natural gas versus 15,000 for the DRL2035.
How big is the glass?
30 in. wide by 16-3/4 in. tall.
Does it work in a power outage?
The fireplace runs on four AA backup batteries during an outage; the blower does not.
What vent pipe does it use?
Superior Secure Vent SV4.5 or Secure Flex, top vent, with up to 60 ft of combined run.
Related reading: Direct Vent Gas Fireplace Buying Guide and Best Fireplace for an NYC Apartment.
Warranty
Superior (Innovative Hearth Products) limited 20-year warranty on the gas appliance per installation manual 900994-00; component terms are listed in the warranty that ships with the fireplace.
